Chrome Steel Ball

SUJ2 Bearing Chrome Steel Balls
  • International Equivalent:
  • AISI 52100/ 100Cr6/ 100C6/ SUJ2/ Wks 1.3505/ GCr15
  •  To Share:
  • inquiry
    • SUJ2 Bearing Chrome Steel Balls
    • SUJ2 Bearing Chrome Steel Balls
    • SUJ2 Bearing Chrome Steel Balls
    • SUJ2 Bearing Chrome Steel Balls
    • SUJ2 Bearing Chrome Steel Balls
    • SUJ2 Bearing Chrome Steel Balls
Product information:

CHROME STEEL BALL
This is an oil hardened steel, which is universally used by the ball and roller bearing industry. This steel has very good hardness, very good physical characteristics and excellent wear resistance.

CHROME STEEL BALL

Chrome steel ball/bearing steel ball
1. MaterialAISI 52100/ 100Cr6/ 100C6/ SUJ2/ Wks 1.3505
2. Size Range0.6mm-180mm
3. GradeG10-1000
4. Hardness58-65 HRC
5. Characteristic(a)Mainly used in bearings
(b)Good hardness
(c)Good resistance to deformation with excellent wear resistance
(d)Low corrosion
6. MagneticYes
7. ApplicationBall bearings, bicycles, automobile industry
8. Chemical composition
C%Si%Mn%S%P%Cr%Mo%Cu%Al%O%
min.0.930.150.25------1.35------------
max.1.050.350.450.0150.0251.650.10.30.050.0015
9.PackingStandard: 10kg or 20kg per carton,1 ton per pallet or as customer required
10.Conditioningdry or oiled
11.Delivery timeStock within a short time or 35 days.
CHANGZHOU HUARI STEEL BALL CO., LTD.



100Cr6 CHROME STEEL BALLAISI 52100 CHROME STEEL BALL

APPLICATION OF BEARING STEEL BALLS


  • Bearing steel balls are widely used. The main applications are: as rolling elements of bearings, bicycles, car seat slides, CV joints, grinding media, universal wheels, etc.


MORE STEEL BALLS


  • Steel Balls Stainless Steel Balls/ Chrome Steel Balls/ Carbon Steel Balls/ Tool Steel Balls

  • Metal Alloy Balls Aluminum Balls/ Brass Balls/ Copper Balls/ Tungsten Carbide Balls

  • Plastic Balls PP Balls/ POM Balls

  • Torlon Balls

  • Ceramic Balls

  • Special Balls Coated Balls/ Rubber Coated Balls/ Flying Saucer Balls/ Solid Half Balls

stainless steel ballsChrome Steel BallAluminum Balls

Brass ballsCopper BallsTungsten Carbide Balls

Plastic BallsRubber Coated BallTorlon Balls

Coated BallsFlying Saucer BallsSolid Half Balls


PACKING

steel balls


↓↓↓ Please see the PDF below for more chrome steel ball parameters. ↓↓↓


Standard packing:
